CC04-IP3MV-3M12
$760.00
- 3 Megapixel (2048×1536) @ 30fps
- 2.85mm Lens (6mm Optional )
- M12 Connection
- Triple Stream H.265 & H.264 & M-JPEG
- Night Color With Super High Sensitive Sensor
CC04-IP3MV-3M12
Products
-
$1,350.00 -
$1,065.00
-
$675.00 -
$95.00 -
$730.00
Features
- Triple Stream H.265 & H.264 & M-JPEG
- Max. 3 Megapixel (2048x1536) @ 30fps
- M12 Connection
- Rugged Vibration Damping Mount
- Night Color With Super High Sensitive Sensor
- Supports OnVif (Profile S) Standard
- IP67 Weatherproof / Dustproof
Specifications
| SPECIFICATIONS | CC04-IP3MV-3M12 |
| Imaging Sensor | ½.8” 3.21MP Sony Starvis PS CMOS |
| Lens | 2.85mm (F1.6) |
| Day & Night | True Day & Night (ICR) |
| Min. Illumination | Color : 0.05 lux / B/W : 0.0005 lux (IIR ON) |
| System | Ambarella 32biit Embedded Linux, 256Mbyte SDRAM, 12Mbyte NAND Flash |
| Compression | H.265, H.264, M-JPEG, |
| Resolution | 2048x1536 / 1920x1080 / 1280x720 704x480 / 640x352 / 320x176 / 160x96 |
| Frame Rate | Max 3 Megapixels (2048 x x1635) @30 fps |
| Motion Detection | 4 Areas |
| Privacy Masking | 8 Areas |
| Connection | M12 Connection |
| Video Stream | Triple Streaming, selectable : H.265 / H.264 / MJPEG, Frame rate, Bit rate, VBR / AVBR / CBR / ACBR / GOP |
| Exposure Mode | Indoor / Outdoor |
| AE Metering Mode | Spot / Center / Average / Venter Flip |
| Shutter Control | Manual (Min. /Max. Setting ) Auto |
| Max AGC Gain | 0-72 |
| Sense Up Level | Off / 1 / 2 |
| Back Light-Compensation | Enable / Disable |
| Auto Exposure | 25%-400% |
| Playback Mode | DOL WDR ( Enable / Disable) D-WDR 0-128 |
| Image Adjustment | Brightness / Contrast / Hue / Saturation / Sharpness |
| White Balance | Auto / Manual / 9 Special Condition |
| 3DNR | 0-11 |
| Day & Night Control | Color / Black & White / Auto Night / Color (B/W, 10 ,20, 30, 40, 50) |
| Image Direction | Vertical Flip / Horizontal Flip / Corridor Mode |
| Programing Interface | SDK, ONVIF Profile S |
| Illuminator | 8 IR LED’s Max. Distance 32.8 ft (10 Meter) |
| Power Supply | SMPS, DC12V 1Amp & PoE IEEE 802.3af |
| Power Consumption | Max. 5.2W |
| Operating Temp. | -10C ~ + 50C, 10% ~ 90% RH |
| Dimension | 80 (W) X 50 (D) X 54 (H) mm |
| Weight | About 515g without Power supply |
| Approval | KC, CE, FCC, RoHS, IP67 |
Document & Download
- 3 Megapixel (2048×1536) @ 30fps
- 2.85mm Lens
- M12 Connector
- Triple Stream H.265 & H.264 & M-JPEG
- Night Color With Super High Sensitive Sensor
