Feature
- 3 Megapixel Resolution
- AISI 316 Stainless Steel Housing
- 2.8~12mm Megapixel Lens
- True Day/Night with ICR Mechanism
- SMART IR - Enhanced Night Vision
- Corrosion / Bacteria Resistant
- SENS-UP for Extreme Sensitivity
- IP67 Waterproof / Dustproof
Specifications
| SPECIFICATIONS | CC06-ND12VF5-M |
| Video Encoding | H.264/MJPEG(simultaneous dual stream) H.264/H.264 (true H.264 dual streaming) Simultaneous streaming with independent control |
| Resolution | 2560x1920, 2048x1536, 1920x1080, 1280x720,640x352, 320x176, 160x96 |
| Serial Interface | Console, By-pass command to control UART device |
| Bandwidth Management | Frame rate control / Bandwidth control I CBR / VBR |
| External Interface | 10/100-Base-T Ethernet (auto-sensing), 1 DVDO(3.3V TTL), |
| Image Sensor | 1/2.9" progressive scan CMOS Total number of pixels: 2000Hx1241V=2.48M Pixel size : 2.5 8 (H) μm x 2.5 8 (V) μm Color filter Bayer arrangement of primary colors: R, G, B Bit number of internal ADC: 10/12 bits Parallel output: 37 .125 MHz, 10/12 bits Maximum frame rate in all-pixel scan mode: 60/30 fps |
| Image Controls | Day & Night (Auto/B&W/O11), AWB, Noise Filter (Off/On), |
| Illumination | 0.0016 Lux |
| Lens / IR | 2.8-12m m Varifocal Lens / 24 Pc IR LED |
| Housing | AISI SS316 / IP67 Environmental Rating |
| Power | Built-In PoE (IEEE 802.3af) or 12V DC (4.8W Max) |
| Operating Humidity | 30%~ 90% |
| Dimensions | 76mm x 159mm I 3.0" x 6.26" |
| Operation Temp. | 14°~122° F (-10°~50° C) |
| Weight | 920g I 2.03 Lbs. |
Documents & Downloads
- 5 Megapixel Resolution
- 2.8~12mm Megapixel Lens
- SMART IR – Enhanced Night Vision
- h.264 High Video Compression
- PoE / 12V DC
